Solar & Renewable
110V DC Bus / 230V AC Single-Phase Pure Sine Wave • 11 kVA / 8.8 kW Continuous Output
Raghu Batteries Quality Guarantee
100% Factory Acid Filled & Formed. High vibration resistance with anchor-bonded plates and heat-sealed polypropylene container.
OFFICIAL SPECIFICATIONS // FLASH-PCU-11KVA-110V
Flash 11kVA / 110V Pure Sine Wave Solar Power Conditioning Unit (PCU)
Manufactured by Raghu Batteries Consulting (Est. 2006), Rajasthan
₹89,999Trade & Retail Inquiry36 Months Comprehensive On-Site Warranty
Heavy industrial-grade Solar Power Conditioning Unit (PCU) featuring high-efficiency MPPT charge controller and pure sine wave inverter. Intelligently prioritizes solar energy over grid electricity to maximize savings and assure uninterrupted industrial and commercial operations.
Nominal Voltage110V DC Bus / 230V AC Single-Phase Pure Sine Wave
Rated Capacity11 kVA / 8.8 kW Continuous Output
Dimensions650 x 480 x 850 mm
Weight (Filled)98.0 kg
RECOMMENDED APPLICATIONS:
Industrial Plants, Commercial Buildings, Solar Micro-Grids & Petrol Pumps
Full Technical Specifications Table
Verified electrical and physical engineering ratings for model FLASH-PCU-11KVA-110V
| Model Designation | FLASH-PCU-11KVA-110V |
| Category | Solar & Renewable |
| Nominal Voltage | 110V DC Bus / 230V AC Single-Phase Pure Sine Wave |
| Rated Capacity | 11 kVA / 8.8 kW Continuous Output |
| Dimensions (L x W x H) | 650 x 480 x 850 mm |
| Filled Weight | 98.0 kg |
| Grid / Spine Technology | DSP Controlled Pure Sine Wave with Integrated MPPT Solar Charger |
| Official Warranty | 36 Months Comprehensive On-Site Warranty |
| Model Code | FLASH-PCU-11KVA |
| Nominal Power Rating | 11 kVA (8800 Watts continuous) |
| DC Bus Voltage | 110V DC (10 Battery Configuration) |
| Solar Charger Type | High Efficiency MPPT Tracker (Up to 98% Efficiency) |
| Output Waveform | Pure Sine Wave (THD < 3%) |
| Display | Multi-Function Graphical LCD & LED Status Matrix |
| Protection | Overload, Short Circuit, Reverse Polarity, Lightning Surge Protection |
| Certifications | ISO 9001:2015 & MNRE Compliance Standards |
| Manufacturer | Raghu Batteries Corporations |
| Legal Manufacturer | Raghu Batteries Consulting (Operating Brand: Flash Batteries), Rajasthan, India |
